A valuable page of reference for researchers into the production of the Birmingham Small Arms Company

It has always been our aim to make freely available to scholars

as much of our archived information of this nature as possible.

We appreciate that, in their original form, these catalogues are in the public domain; however, the research, difficult and costly acquisition, archiving and photographic work undertaken by our volunteers over more than twenty years was being taken and used, even sold, elsewhere with neither permission nor recognition. We regret that, as a result of this plagiarism,we found it necessary to temporarily remove these files, but have now restored them, with yet more throughout the site for your own research. Please respect our copyright.

These are the complete catalogues marketing full-bore Service,

sporting and target rifles, sights and accessories,

in addition to their shotguns, and some air-rifle production, but importantly including

THE B.S.A. MINIATURE TARGET & TRAINING RIFLES

as illustrated in various BSA General Catalogues through the years

See also notes on the BIRMINGHAM SMALL ARMS COMPANY history

and the many reference pages for the B.S.A. small-bore target rifles

Also on site is the complete Handbook for the 1906 Pattern War Office Miniature Rifle - which may be viewed from that page

You may also view a catalogue for WW.Greener's products, including their miniature rifles and accessories

This page provides access to PDF files of copies of various BSA Catalogues from 1908 onward

Click on the image of each catalogue cover to view as a flip-page document.

These files are in considerable detail, which zooming-in will reveal if required.

You may require Adobe Acrobat Reader to be installed on your computer

Firstly the 1908 catalogue

1909 Edition 2

The Book of the BSA AIR RIFLE - ca. 1910

In 1912 BSA also published a brochure on the cleaning of their rifles.

Circa 1912-14, BSA issued this catalogue specifically dealing with Front and Rear Sights,

"For all kinds of rifles" was the description of content.

The all-products Rifles and Rifle Sights catalogue,

contemporary with the previously listed Sights only catalogue, is shown below.

The following catalogue was probably published only a year or two after the one above, so we do not repeat the entire facsimile. It was identical except for a very few differences, the most obvious of which is that the useful, but no doubt more costly to produce, section tabs of the previous edition were dispensed with. Internally, this later edition had only a few additional inclusions and omissions.

We noted that the A.G. Parker rear-sight with the Tippins designed folding Ross M10 leaf, for the 'Long' Lee-Enfield, was no longer present. Indeed, in the previous edition there was an addendum tag on page 28 noting that

" The stock of B.S.A.-Parker Sights has been handed over to Messrs. A.G. Parker & Co. Lt., Bisley Works, Whittall Street, Birmingham. Enquireies regarding thes sights should be addressed to them"

After B.S.A.'s stocks of these sights had been tranferred to Parkers, BSA then only advertised their own design under the No.9 numbering models A through G over the following years.

The removal of this information on page 28 allowed its replacement with fitting instructions for the No.8 folding rear aperture sight in its various heights. The sights themselves remained on the opposing page 29.

There was an increase in the cost of the B.S.A. "Adder" air-rifle pellets, which was shown using another glued-in amendment sticker.

Page 31, of the B.S.A. Foresights for Target and Sporting Rifles, had a paragraph added advising that the No.19 combination fore-sight was now "fitted with an outside lever ( not illustrated ) by means of which the sight angle may be readily turned over when the second alternative is required. In this new design the angle is held firmly in either of its two correct positions. The price of the improved sight is as before". This refers to the flip-over option of a blade or an aperture fore-sight element, which had previously required a fine screwdriver to make the change from one to the other.

It is not particularly encouraging to be reminded how little most prices then altered over periods of several years, compared with today's frightening rates of inflation.

The next amendment was to page 32 for the Wind-Gauge Sight Slides, from which the two No.3 pattern slides were removed, as well as the No.2 and No. 5 elevation leaves. The space released was used to advertise the books "Notes on rifle Cleaning", and "The Complete Air Gunner". Not that the latter term was then used in the nowadays more commonly understood way, before the second understanding of it was to become well-known with the advent of the brave air-gunners of the First and Second World Wars.

Page 46 is, in both catalogues, for the "B.S.A. Martini Rifles - SPECIAL TARGET PATTERNS", and the only alteration here was that the quoted 1911 World's Record had been updated from the following

"World's Record at the three ranges - 100, 50 and 25 yards (squadded shoot):

299 out of a possible 300, was made in 1911 by Mr. J. Pepe, Southfields and Daily Telegraph Clubs, with a B.S.A. Martini Target Rifle [ It is not stated which model]

"WORLD'S RECORD MADE WITH A B.S.A. No.12 MODEL TARGET RIFLE

Mr. Oldman, of Norfolk, won the Eastern Open Championship at Market Rasen in September, 1912, with the magnificent score of 587 (deliberate and rapid), out of a highest possible of 600 - six better than the previous world's best. His rifle was fitted with a B.S.A. No.8 aperture sight and No.19a fore-sight."

View our site page exclusively detailing the B.S.A. Model No. 12 Rifle

The previously blank page 48 at the end of the catalogue became that for the B.S.A. No.2 Folding (Pocket) .22 Rifle, retaining the same 48 page format to the document.

As mentioned, it is pointless to include all the identical pages in the PDF,
so we have only shown the four main amendments.

In December of 1917, BSA advertised on the whole front cover of "The Rifleman".

This was the journal of the Society of Miniature Rifle Clubs, encouraging readers to enquire of post-war products. Already it was obviously hoped, perhaps rather optimistically, that the War could not last much longer and that it was necessary to consider ongoing civilian commercial needs. In the event, nearly another year was to pass before the Great War ended , with terrible further loss of life, officially at 11:00 a.m. on the 11th. of November 1918.

In July 1919 BSA published their first post First World War Catalogue - noted as being "Preliminary", but compared with the later 1919 edition - available as a reproduction, only the artwork framing each page is different. The content of the catalogue is identical.

It included Service rifles, full-bore sporting rifles, small-bore rifles, air rifles, shotguns and accessories.

This was a remarkable achievement at a time when it was critical, for the survival of the Company and the jobs of as many of its staff as practicable, that the now cancelled war-time military small-arms contracts were replaced by as much civilian production for general consumption as the Company could muster.

A page from a mid 1920s B.S.A. catalogue, particularly expounded the virtue of the Model 12 rifle and still detailing its World Record achievement mentioned earlier

In 1921 BSA Guns Ltd. published an excellent booklet detailing the manufacture of their accurate miniature rifles. It affords an inside view of the Small Heath works and the materials and processes involved in making the company's products.

BSA Miniature Rifle Manufacture 1921
